Mitech MHVS-1 Digital Micro Vickers Hardness Tester
Mitech MHVS-1 Vickers Hardness Tester
Brand：Mitech
Model：MHVS-1
Measuring range：5~2500HV
Resolution Accuracy：
Communication storage：
Working time：
Main unit weight：
Dimensions：
Package dimensions：66*44*77cm
Total weight：75kg
Mitech MHVS-1digital micro hardness tester, based on the principle that positive quadrangular pyramid diamond indenter presses the surface of the sample to produce indentation.By measuring the diagonal length of the indentation to achieve the measurement of the hardness of the material can be for small specimens, thin specimens, surface coating, heat treatment of the workpiece surface Vickers hardness test. Adopted computer-aided, high-rate optical measurement system, photoelectric sensor technology, adjustable light, it is the upgrading products of universal type of micro hardness tester and widely used in the fields of metal processing, electronics industry, mold parts, watch manufacturing, engineering quality inspection and so on. It is an ideal hardness tester for material research and testing.
Function & application
Metal processing manufacturing quality control links
University education teaching demonstration experiment
Failure analysis test of metal material
Testing of material hardness of scientific research institutions
Quality inspection departments quality testing links
Micro-Vickers (or Knoop) hardness test principle is that put the provisions of the positive pyramid diamond indenter into the sample surface(with fixed experimental force) and maintain a certain length (holding), and then unloading. Finally, there is a positive quadrangular pyramid or kenup indentation with a square surface on the surface of the specimen. Then we can attain the area of indentation via measuring the length of the diagonal by a micrometer eyepiece. Then the corresponding Vickers (or Knoop) hardness values are obtained.
Technical Product
| Test force | 98.07N，tolerance ±2.0%10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、 200gf (1.96N)、300gf ( |
| Measuring range | 5~2500HV |
| Convert ruler | HRA、HRB、HRC、HRD、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T、HV、HK、HBW |
| Display attributes | LED Digital Display |
| Applying way of test force | Automatic (loading, holding, unloading) |
| Conversion way of indenter | Manual |
| Magnification of measure microscope | 100X(observing )400X(measuring) |
| Test force holding time | 0~60s |
| Minimum resolution | 0.0625μm |
| Maximum height of specimen | 75mm |
| Maximum width of specimen | 95mm |
| Power supply | AC220V/50Hz |
| Dimension | 441*270*480mm |
| Main unit weight | 31kg |
‘
‘
‘
