Mitech MT-1A Portable Magnetic Particle Flaw Detector
Brand：Mitech
Model：MT-1A
Measuring range：1mm
Resolution Accuracy：
Communication storage：USB
Working time：＞4h
Main unit weight：Main unit 0.75 KG,magnetic yoke 1.5KG(including cable line）
Dimensions：100*204*36mm
Package dimensions：44.5*37*17cm
Total weight：7.5kg
MT-1A digital portable magnetic flaw detector, adopts large capacity lithium battery power supply. DC is exchanged into AC by the inverter and the phase shifted signal processor to provide power for the detector, it solves the shortcomings of traditional magnetic particle detector relying on the 220V power supply. It has low power consumption and can continuous work for more than 4 hours. The battery can be charged while working or off. It can real-time monitoring, process image, save data, print the test report, track inspection results, meet the requirements of standard operation and management. Especially suitable for the field without power supply field testing and high-altitude operations, it realizes the innovation of magnetic powder digital inspection.
It is widely used in the industry of aircraft manufacturing, boiler and pressure vessel, electric, oil field, shipbuilding, turbine and combustion engine parts, mine, machinery, standard parts, oil pump, vehicle parts, bridging, chemical, railway, large mechanical components, steel structure equipment etc. It mainly detects the surface detection of forging, quenching, welding, fatigue, for example, irregular workpiece of chain, crankshaft, bearing, high strength bolt, spring, forging, petrochemical pipe, valve, vane, gear, anchor chain, welding seam etc.
Technical Product
| Lighting | white/fluorescent |
| Dimension | 204mm×100mm×36mm |
| Main unit | 0.75 kg（including battery） |
| Screen dimension | 3.5 inch |
| Working voltage | DC 15V-21V |
| Output curve | alternating curent pulse |
| Probe dimension | 174mm×162mm×38mm |
| Polar distance | 75-200mm |
| Yoke weight | 1.5kg(including line） |
| Cable line length | 1.2 m （can be customized） |
| Lifting force | ＞45N（more than 5Kg） |
| Complex sensitivity | Notch clear on A1 15/100 standard specimen |
| Continuous working hours | ＞4h |
| Battery dimension | 79mm×58mm×18mm |
| Li-battery weight | 0.52kg |
| Battery voltage | 18V |
| Battrey capacity | 8400mAh |
| Charging limited voltage | 21V |
| Power supply | 220V 50HZ |
| White light illumination | ＞1000lx |
| Distance between light and workpiece | 100mm |
| Fluorescence center wavelength | 365mm |
| Fluorescence amplitude | ＞1000μw/c㎡ |
‘
‘
‘
