Mitech MHVS-10 Digital Vickers Hardness Tester
Mitech MHVS-10 Vickers Hardness Tester
Brand：Mitech
Model：MHVS-10
Measuring range：8HV0.3~2500HV10
Resolution Accuracy：
Communication storage：
Working time：
Main unit weight：40kg
Dimensions：
Package dimensions：66*44*77cm
Total weight：75kg
Mitech MHVS series digital vickers hardness tester, based on the principle that positive quadrangular pyramid diamond indenter presses the surface of the sample to produce indentation.By measuring the diagonal length of the indentation to achieve the measurement of the hardness of the material can be for small specimens, thin specimens, surface coating, heat treatment of the workpiece surface Vickers hardness test. With stable performance, strong structure, high reliability, simple operation, adopt digital display and high magnification optical measurement system, adjust the cold light source, photoelectric sensing technology and computer-aided means it has a powerful function. It is widely used in the fields of metal processing, electronics industry, mold parts, watch manufacturing, engineering quality inspection and so on. It is an ideal hardness tester for material research and testing.
Technical Product
| Test force | 2.94N、4.9N、9.8N、29.4N、49N、98N |
| Measurement range | 8HV0.3~2500HV10 |
| Hardness symbol | HV0.3、HV0.5、HV1、HV3、HV5、HV10 |
| The conversion mode of the head and the objective lens | Manual operation |
| Loading and unloading mode | Automatic operation |
| Magnification of measuring microscope | 200x（testing） 100x（observing） |
| Minimum detection unit | 0.01μm |
| Maximum height of applicable materials | 160mm |
| Test to secure the load time | 0~60s |
| Maximum distance from the center of the head to the machine wall | 135mm |
| Display | LCD digital display |
| Power supply | AC220V/50Hz |
| Dimension of Exterior | 540*220*650mm |
| Machine weight | 40kg |
‘
‘
‘
